• Rating：6A 125VAC;3A 250VAC
• Contact Resistance：50mΩ Max
• Insulation Resistance：DC 500V 100MΩ Min
• Dielectric Strength：AC 1000V 1 minute
• Operation Force：250±50gf
• Total Travel：2.4±0.4mm
• Operation Life：10,000 cycles
• Machanical Life：50,000 cycles Min
• Operation Temperation：0℃ ~+85℃
• Function：OFF-(ON)
|
 |
   |
| Part Number | Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operation Force | Total Travel | Operation Life | Machanical Life | Operation Temp. | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|---|
| R0197-02-PM-B | 6A 125VAC;3A 250VAC | 50mΩ Max | DC 500V 100MΩ Min | AC 1000V 1 minute | 250±50gf | 2.4±0.4mm | 10,000 cycles | 50,000 cycles Min | 0℃ ~+85℃ | 暫無(wú) |
| R0197-02-PM-Y | 6A 125VAC;3A 250VAC | 50mΩ Max | DC 500V 100MΩ Min | AC 1000V 1 minute | 250±50gf | 2.4±0.4mm | 10,000 cycles | 50,000 cycles Min | 0℃ ~+85℃ | 暫無(wú) |
| R0197-02-MM-G | 6A 125VAC;3A 250VAC | 50mΩ Max | DC 500V 100MΩ Min | AC 1000V 1 minute | 250±50gf | 2.4±0.4mm | 10,000 cycles | 50,000 cycles Min | 0℃ ~+85℃ | 暫無(wú) |
